Onkyo TX-NR509

Audio Video Receiver (2011-12)

Specifications

Tuning range: FM, MW

Power output: 80 watts per channel into 8Ω (stereo)

Surround output: 80W (front), 80W (center), 80W (rear)

Frequency response: 20Hz to 50kHz

Total harmonic distortion: 0.08%

Damping factor: 60

Input sensitivity: 200mV (line)

Signal to noise ratio: 100dB (line)

Output: 200mV (line)

Speaker load impedance: 6Ω to 16Ω

Digital inputs: coaxial, optical

Video Connections: HDMI, component, composite

Dimensions: 435 x 173.5 x 328mm

Weight: 9.5kg

Year: 2011
